Hisense Duct Split

If you are interested in reviewing and selecting Hisense duct split units among various brands, stay with us in this article. After a brief introduction to the Hisense brand, we will familiarize you with the different types of duct splits from this brand in terms of capacity, technical specifications, warranty, reasonable prices, and more.

Review and Selection of Hisense Duct Split

Hisense company was established in 1969 in China, initially producing various household appliances, and today it has become one of the top 10 household appliance manufacturers in the world.

Hisense has expanded its operations with 22 subsidiary companies in over 200 countries worldwide. Due to its diverse models and the quality of after-sales service, it has gained popularity among consumers. Today, the company has over 13 factories producing household appliances and electronics, including air conditioning equipment, worldwide. Among the air conditioning equipment produced by Hisense are various air conditioners, fan coils, duct splits, and more.

DamaTajhiz HVAC Co.; Engineering, Manufacturing, and Trading Company in the Middle East Since 2004
Review, Selection, and Pricing of HVAC Equipment

What factors make Hisense Duct Split an ideal choice?

Hisense ceiling duct split is an excellent option both in terms of quality and price for use in homes and offices. It consists of an internal unit installed in the false ceiling of the building and an external unit connected to the internal unit via copper pipes. The Hisense duct split, with ductwork installation, can supply air to multiple spaces at the desired temperature, making it highly cost-effective.

Hisense Ducted Split

Variety of Models and Capacities of Hisense Ducted Splits

All Hisense ducted split units available on the specialized reference site DamaTajhiz are equipped with inverter technology and are offered in various capacities ranging from 18,000 to 60,000 BTU/hr. Dear customers, you can review the technical specifications and guaranteed prices of different models of Hisense ducted split or channel split units on this page.

Compressor and Refrigerant Gas Used in Hisense Ducted Splits

Hisense uses rotary compressors in the production of its ducted split units. The rotary compressor is the most common type used in ducted splits, and units equipped with inverter kits consume less electricity and energy.

Additionally, the refrigerant gas used in Hisense ducted splits is R410, which is completely environmentally friendly.

Features and Advantages of Hisense Ducted Split Units

The key features and advantages of Hisense ducted split units include the following:

HI-NANO:

Releases a large number of ionic streams that help eliminate bacteria and viruses present in the surrounding air (through recycling).

Multiple Airflow Options:

Hisense ducted split units come with remote control, allowing you to adjust airflow angles and different air supply options to meet various needs.

Smart Airflow:

Hisense ducted split units are available in different models with "ceiling airflow" and "floor airflow" options.

Anti-Bacterial Fins:

The anti-bacterial fins in Hisense ducted split units enhance anti-bacterial and anti-mold performance, providing a great solution for healthy, clean air.

High Energy Efficiency:

Using inverter technology, the internal air duct of the split unit is optimized, reducing electricity consumption by up to 30%.

Wi-Fi Control:

This technology in some Hisense ducted split models allows you to control the unit both inside and outside the home effortlessly.

Types of Hisense Ducted Split Systems

Table for Reviewing and Comparing Technical Specifications and Purchase Prices of Hisense Ducted Split Systems

The table below provides technical information and the best purchase prices for various Hisense ducted split systems:

Note: The power consumption (amperage) mentioned in the table represents the maximum current consumed by the unit in either cooling or heating mode.

Hisense Duct Split Series HID

Model	Capacity (BTU/hr)	Compressor Type	Power Consumption (phase/ A)	Inverter Kit	Indoor Unit Dimensions (mm) Length x Width x Height	Noise Level - H/M/L (dB)	Price (Toman)
HID-18	18000	ًRotary	Single-phase/ 6.5	Available	1170x190x455	39/37/35	45,654,700
HID-24	24000	Rotary	Single-phase/ 8.1	Available	900x270x720	40/38/36	59,537,600
HID-30	30000	Rotary	Single-phase/ 11.9	Available	1140x268x720	41/38/33	71,912,700
HID-36	36000	Rotary	Single-phase/ 16.9	Available	1140x268x720	46/44/42	75,803,900
HID-48	48000	Rotary	Three-phase/ 5.8	Available	1300x350x800	46/44/42	108,162,600
HID-60	60000	Rotary	Three-phase/ 9.3	Available	1300x350x800	46/44/42	Inquiry-based

Guide for Determining the Capacity of Hisense Ducted Splits

To determine the required capacity of Hisense ducted splits for your project, please send the latest architectural plans of your units and building floors via fax or email to our experts.

For an approximate estimate of the required cooling capacity for each apartment in weather conditions similar to Tehran and for middle-floor units (not exposed to direct sunlight on the ceiling in the summer or cold from the roof in the winter), about one ton of cooling (each ton equals 12,000 BTU per hour) is considered for every 30 or 40 square meters of the gross apartment area.

If your apartment units are up to 200 square meters, you can use single-phase ducted splits with 50-amp power supply.

Another important consideration when selecting and purchasing a ducted split is the air delivery volume, which is usually approximately 400 CFM for each ton of ducted split capacity. Naturally, if the airflow volume is lower, the noise level of the ducted split will be lower, and if the airflow is higher, the noise level will increase.

The following approximate calculation table is provided to help determine the required ducted split capacity based on the mentioned conditions and calculations.

Ducted Split Capacity (BTU)	For Middle and Ground Floor Units (m2)	For Units Below the Roof (m2)
18000	to 45	to 35
24000	to 60	to 45
30000	to 80	to 60
36000	to 100	to 80
48000	to 130	to 100
60000	to 150	to 130

-Attention: This calculation is approximate and intended solely for residential apartments with weather conditions similar to those in Tehran, with a ceiling-to-floor height of 2.8 meters, without accounting for the accumulation of people, increased latent heat, or the use of high-energy-consuming electrical equipment. It also assumes there is no glass facade or glass walls, particularly on the west side of the space or building.

After determining the required capacity and number of ceiling duct split systems, their placement location is determined based on various parameters such as the presence of a false ceiling, the possibility of duct installation, the way the pipes are connected to the external unit, the way the hot water piping is installed to the heating coil, the optimal installation position considering sound levels, etc.
The ducting plan from the ceiling duct split to each space (hall or rooms) is prepared and sent, based on the most appropriate dimensions and routing above the false ceiling.
Given the frequent questions from residential unit builders regarding the cost of installing air distribution and return ducts inside units and copper piping between the internal duct and external panel, a rough estimate of the cost for these installations is about 20 to 30 percent of the initial purchase price of the duct splits. (This estimate is approximate and depends on factors such as the length of the path, the distance between the two panels, and other factors.)
Before selecting and ordering the purchase of any of the above ceiling duct splits, please ensure that you pay attention to the required electrical phase (Ø), as well as the amperage (A) based on the power and specifications of your unit's electricity meter.

Buying Hisense Duct Split Systems

There are important factors to consider when selecting and purchasing a duct split, and the first step in choosing a good duct split is to accurately determine its type, capacity, and brand. It is important to note that the calculation of the duct split capacity should be done in consultation with a specialist and expert. Additionally, when purchasing a duct split, you should also pay attention to its electricity consumption and amperage.

On the Damatajhiz specialized website, technical information for dozens of models of duct splits from reputable brands with original warranties is provided, allowing you to experience optimal and smart purchasing.

Price of Hisense Duct Split

Duct splits are generally available in two types: inverter and non-inverter, with the inverter type being priced higher than the regular type. However, the reduction in electricity costs over the years can offset the higher price.

The capacity and brand of the duct split are also two important factors in determining its price.

It is worth mentioning that all the duct splits offered on the Damatajhiz specialized website have a product ID and are priced reasonably, with consumer discounts included in these prices.

Thousands of Products for Thousands of Projects (Since 2004)

Warranty of Hisense Duct Split

Hisense duct splits come with a 5-year warranty for compressor replacement and a 2-year warranty for technical parts from Zarinnama Kaspian Company.

Given the frequent questions from residential unit developers, we would like to inform you that, in general, the cost of installing air distribution and return ducts within the units, as well as copper pipes between the internal duct and external panel of the duct splits, amounts to approximately 20% of the initial price of your duct split, though this percentage is approximate.

Considering that purchasing from specialized and reputable websites and establishments for air conditioning and heating equipment is beneficial both technically and financially, the Damatajhiz specialized website offers technical information and guaranteed prices for various Hisense duct splits with original warranties, providing you with the opportunity for optimal and smart purchasing.
