DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC600

Purchase Guide for DamaTajhiz Concealed Ceiling Fan Coil UnitDT.CFC600

DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC600 is manufactured with 600 CFM of aeration capacity under technical principles and common standards for construction projects.

Technical Specifications of DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC600

•  DamaTajhiz Fan Coil Unit has three-row aluminum and copper coils (with 8 tubes in each row), each with 8.3 inches of diameter and 12 FPI of distance from each other.
• DamaTajhiz coils are manufactured with the most advanced fully automatic machines and have larger heat exchange surfaces compared to other rings due to using sophisticated Fin Plate technology.
• Copper tubes are mechanically integrated onto staggered sinusoidal aluminum plate fins by the Expander machine to eliminate distances between fins and copper tubes.
• After being manufactured, all coils are degreased with a degreasing solution and tested at 200 PSI of pressure.

Specifications of Fan and Electro Motor

The centrifugal fan of the DamaTajhiz Fan Coil Unit is made of ABS with minimum noise, being statically and dynamically balanced with a propylene snail. It should be noted that ABS aeration fans of DamaTajhiz Fan Coil Units can resist up to 100 °C. Moreover, these fan coil units have single-phase three-speed electromotors that are manufactured under the license of the Italian Sisme Company.

The motor has 8 bars of reliable operating pressure for the DamaTajhiz Fan Coil Unit and is suitable for buildings with up to 20 floors.

Frame Specifications

It consists of an inner and outer frame. The inner frame is made of a high-quality 1mm thick galvanized sheet connected to the outer frame with automatic screws and rivets.

Insulation

The device is insulated with a glued-back compressed Airo Flex insulator (3mm thick compressed polyethylene) to prevent heat loss and cold and reduce device noise.

Filtering

Aluminum plates and washable filters can eliminate particles in the air, given the filtering type. In these filters, grid sheets are put on each other.

Distillation Pan

Galvanized distillation pan with a proper slope to direct distilled water from coil surface in warm seasons

Advantages of DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC600

• Highly appropriate size to be installed on false ceilings with low height
• Three standard speeds with low noise
• Electronic heating coils can be used if the customer demands
• Easy access to fan and electromotor for periodic maintenance
• Easily usable deaeration valve
• It can be manufactured with two air return conditions: from below and from back
• Washable and high durable filter with easy installation and replacement
• Insulator used under distillation pan to prevent it from sweating
• High heating capacity with three-row coil

Determination of DamaTajhiz Fan Coil Units Capacity

One of the most important things in selecting fan coil units is determining their capacities. For this purpose, you can use the following approximated table:

Warranty and After-sale Services for DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC600

In the reference and specialized collection of DamaTajhiz, technical information and the best price of ceiling fan coil without temperature cabinet, DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC600 and types of ceiling fan coil without temperature cabinet with golden warranty, have been presented for you to enjoy the good feeling of optimal and smart purchase of a Fan Coil Unit.
