DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC200

  1. Small volume, light, and very quiet type
  2. Special design with small dimensions for optimal placement in the false ceiling (low height)
  3. 4-layer aluminum filter and anti-fungal with the ability to wash, install and replace easily
  4. Proper and integrated insulation (seamless) in order to significantly reduce noise and energy losses
Warranty :

18 months original warranty

Warranty terms :

18 months warranty since installation

after-sale Services :

20 years after-sale Services

$130
Tax excluded
Quantity

New
View all products of دماتجهیز

guide to buying a DamaTajhiz built-in ceiling fan coil 200CFM-DT.CF200

The built-in ceiling fan coils of DamaTajhiz are produced in compliance with all technical principles and conventional standards in the ventilation capacity of 300 to 1200 (CFM) for construction projects and respected consumers.

If you want to supply all kinds of built-in ceiling fan coils, ground or channel, without paying heavy costs, long delivery time, space price, and lack of proper response of most traditional and old brands in the facilities market, you have come to the right place and we sincerely thank you. Congratulations on this! Please, by reading the items presented below and contacting the sales experts of the air conditioning equipment department in the DamaTajhiz collection, you will get a suitable and satisfactory experience of buying from this dynamic collection.

In general, the built-in ceiling fan coil 200CFM, model DT.CF200, with very suitable dimensions, has the ability to be easily installed in all types of false ceilings (with low heights).


DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC200

Advantages of the built-in ceiling fan coil 200CFM, model DT.CF200

  • Small volume, light, and very quiet type
  • The body is made of hard and strong galvanized sheet
  • It has a three-speed centrifugal fan and a three-row coil
  • Equipped with a very easy-to-use air valve
  • It has a galvanized drain tray with standard insulation
  • It has three standard speeds with a very low sound level
  • Use of electric motors with reliable brands as standard or customized
  • Using quality parts and manufacturing conditions according to the world's standards
  • Special design with small dimensions for optimal placement in the false ceiling (low height)
  • The use of a standard blower fan with the ability to install a blower fan made of polyamide with fibers and resistant to high heat as customized

Technical specifications of DamaTajhiz built-in ceiling fan coil 200CFM model DT.CF200

  1. Specifications of Damatajhiz fan coil model DT.CF200
    • The built-in ceiling fan coil200 CFM, model DT.CF200, has 3-row coils of copper pipes with a diameter of 3.8 inches and aluminum fins with a distance of 12 FPI.
    • The coils manufactured by this company are made with the most advanced fully automatic machines and due to the use of advanced fin plate technology, they benefit from a high level of heat exchange compared to similar types of coils.
    • The copper tubes are mechanically integrated by the expander device with the staggered sinusoidal fins of the aluminum sheet. Therefore, any extra distance between fins and copper pipes is eliminated.
    • After manufacturing, all coils are degreased and washed with a special solution, and tested with a pressure of 300 PSI.
    • The reliable working pressure for DamaTajhiz fan coil coils is 8 bar and suitable for buildings up to 20 floors.
  2. Specifications of fan and electric motor
    • Built-in ceiling fan coil 200CFM, model DT.CF200, has a metal centrifugal fan with a minimum sound decibel and with an accurate dynamic and static balance to minimize the noise of the device.
    • The material of the blower fan in the DamaTajhiz ceiling fan coils is of metal type (in standard conditions) and it is possible to install the blower fan made of polyamide with fibers and resistant to high heat (temperature resistance of 120 degrees Celsius), as customized and according to The needs of respected buyers are met.
    • The electric motor of the ceiling fan coils of the heating equipment is of the single-phase, three-speed type and is one of the best available brands with a long lifespan.
  3. Body specifications
    • The body set of the built-in ceiling fan coil of the DT.CF200 model consists of a high-quality galvanized sheet with a thickness of 1 mm, which are connected to each other through self-tapping screws and rivets (in order to eliminate extra sounds).
  4. Insulation
    • The insulation of the built-in ceiling fan coil 200CFM, model DT.CF200, is of compressed Airo flex adhesive back type (3mm compressed polyethylene), in order to prevent the waste of heat, and coldness and significantly reduce the sound of the device.
  5. Filter
    • A 4-layer flat aluminum filter that can be washed and is able to easily remove dust and suspended particles in the air due to its filtration type.
    • The structure of these filters consists of aluminum mesh plates that are placed on top of each other and have the ability to be replaced and moved easily for washing.
  6. tray in
    • The drain tray in the ceiling fan coils is made of galvanized material or compact ABS with a suitable slope, to collect and direct the distilled water from the surface of the coil and direct them to the drain pipe.

Determination of DamaTajhiz Fan Coil Units Capacity

One of the most important things in selecting fan coil units is determining their capacities. For this purpose, you can use the following approximated table:

Fan coil capacity determination table

Warranty and After-sale Services for DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC300

  • In the reference and specialized collection of DamaTajhiz, technical information and guaranteed prices for purchasing DamaTajhiz fan coils in different models and capacities with a golden guarantee have been provided, so that you, dear ones, can enjoy the good feeling of optimal and smart shopping.
  • Built-in ceiling fan coil 200CFM DamaTajhiz model DT.CF200 has an 18-month golden warranty and 20 years of after-sales service by DamaTajhiz company.

contact damatajhiz

Device model

DT.CF200

Device installation position built-in ceiling
Aeration capacity (CFM) 200
Coil specifications Number of rows 3
Size of copper pipes (inch) 3/8″
fin per inch (Fpi) 12
Cooling capacity (BTU/hr) 11800
sound level dB(A) High 40
Medium 35
Low 32
Water flow (GPM)
2.5
Inlet water pipe diameter (mm)inch  (19.05) 3/4
The diameter of the outlet water pipe (mm)inch  (19.05) 3/4
The diameter of the drain pipe (mm)inch  (19.05) 3/4
dimensions of the device (mm) 205X550X600
