DamaTajhiz decorative Floor-mounted Fan coil unit 900CFM model DT.GC900

Guide to choosing and buying DamaTajhiz decorative Floor-mounted Fan coil unit 900CFM model DT.GC900

DamaTajhiz decorative Floor-mounted Fan coil units are manufactured in compliance with all technical principles and conventional standards in the ventilation capacity of 300 to 1000 (CFM) for construction projects and respected consumers.

If you want to supply all types of ground, ceiling, wall, or channel fan coils, without paying heavy costs, long delivery time, space prices, and lack of adequate response from most of the traditional and old brands in the facilities market, you have come to the right place and sincerely. Congratulations on this! Please, by reading the items presented below and contacting the sales experts of the air conditioning equipment department in the DamaTajhiz collection, you will get a suitable and satisfactory experience of buying from this dynamic collection.

In general, the decorative Floor-mounted fan coil unit 900CFM model DT.GC900 with very suitable dimensions, high efficiency, and easy installation is suitable for use in residential complexes and construction projects.

Technical specifications of Damatajhiz decorative Floor-mounted Fan coil unit900CFM model DT.GC900

1.  Specifications of Damatajhiz Fan coil unit

•  DamaTajhiz Fan coil unit 900CFM model DT.GC900 has 3-row coils of copper pipes with a diameter of 3.8 inches and aluminum fins with a distance of 12 FPI.
•  The coils manufactured by this company are made with the most advanced fully automatic machines. Due to the use of advanced fin plate technology, they benefit from a high level of heat exchange compared to similar types of coils.
•  The copper tubes are mechanically integrated by the expander device with the staggered sinusoidal fins of the aluminum sheet. Therefore, any extra distance between the fins and the copper pipes is eliminated.
•  After manufacturing, all coils are degreased and washed with a special solution, and tested at a pressure of 300 PSI.
•  The reliable working pressure for the fan coil unit of the DamaTajhiz coils is 8 bar and suitable for buildings up to 20 floors.

2.  Specifications of the fan and electric motor

•  DamaTajhiz decorative Floor-mounted Fan coil unit 900CFM model DT.GC900 has a metal centrifugal fan with a minimum sound decibel and with an accurate dynamic and static balance to minimize the sound of the device. Also, the material of the blower fan in the Damatajhiz decorative Floor-mounted fan coil units is metal type (in standard conditions) and it is possible to install the blower fan made of polyamide with fibers and resistant to high heat (temperature resistance (C°) 120) as a custom and it is provided according to the needs of respected buyers.
•  Also, the electric motor of the DamaTajhiz decorative Floor-mounted Fan coil unit is of the single-phase three-speed type and is one of the best available brands with a long lifespan.

3.  Body specifications

• The main body of the Floor-mounted Fan coil unit is made of ABS material, the connecting profiles are made of aluminum and the drain tray is made of a hot galvanized sheet with polyester electrostatic powder paint coating.

4.  Insulation

• The 900CFM decorative floor fan coil unit insulation of the DT.GC900 model is of compressed Airo flex adhesive back type (3mm compressed polyethylene), in order to prevent the waste of heat, and coldness and significantly reduce the sound of the device.

5.  Filter

• A 4-layer, washable flat aluminum filter, which, according to its filtration type, is able to easily remove dust and suspended particles in the air, and the structure of these filters is such that the aluminum mesh sheets are placed on top of each other and have They can be replaced and moved easily and conveniently for washing.

6. tray in

• The drain tray in the Floor-mounted Fan coil unit is made of galvanized material or compact ABS with a suitable slope, to collect and direct the distilled water from the surface of the coil and direct them to the drain pipe. (To prevent decay, the drain tray is covered with epoxy powder paint.)

7. air outlet

• The air outlet port of the decorative Floor-mounted Fan coil unit is made of ABS material (very high quality) with the ability to adjust in desired directions.

Advantages of DamaTajhiz decorative Floor-mounted Fan coil unit 900CFM model DT.GC900

• The body is made of ABS material (hard and strong).
• It has a three-speed centrifugal fan and a three-row coil
• Equipped with a very easy-to-use air valve
• It has a galvanized drain tray with standard insulation
• It has three standard speeds with a very low sound level
• Use of electric motors with reliable brands as standard or customized
• Using quality parts and manufacturing conditions according to the world's standards
• The use of a standard blower fan with the ability to install a blower fan made of polyamide with fibers and resistant to high heat as customized

Determine the capacity of temperature equipment fan coil units

One of the most important points in choosing a fan coil unit is to determine its capacity. For this purpose you can refer to the approximate table below:

Purchase order and warranty of DamaTajhiz decorative Floor-mounted Fan coil unit 900CFM model DT.GC900

In the reference and specialized collection of DamaTajhiz, technical information and the best price of DamaTajhiz fan coils in different capacities with a golden guarantee have been provided, so that you, dear ones, can enjoy the good feeling of an optimal and smart purchase.

To view and learn about the technical specifications of the decorative Floor-mounted Fan coil unit, please click on the "Technical Specifications" tab on the page of each product.

DamaTajhiz decorative Floor-mounted Fan coil unit 900CFM model DT.GC900 has an 18-month golden warranty and 20 years of after-sales service by DamaTajhiz company.
