Selection and Purchase Guide for DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000

DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000 is manufactured with 1000 CFM of aeration capacity under technical principles and common standards for construction projects.

Technical Specifications of DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000

Specifications of DamaTajhiz Fan Coil UnitDamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000

  • DamaTajhiz Concealed Ceiling Fan Coil Unit has three-row aluminum and copper coils (with 8 tubes in each row), each with 8.3 inches of diameter and 12 FPI of distance from each other.
  • DamaTajhiz coils are manufactured with the most advanced fully automatic machines and have larger heat exchange surfaces compared to other coils due to using sophisticated Fin Plate technology.
  • Copper tubes are mechanically integrated onto staggered sinusoidal aluminum plate fins by the Expander machine to eliminate distances between fins and copper tubes.
  • After being manufactured, all coils are degreased with a degreasing solution and tested at 200 PSI of pressure.

Specifications of Fan and Electro Motor

Centrifugal fan of DamaTajhiz Fan Coil Unit is made of ABS with minimum noise, being statically and dynamically balanced with a propylene snail. It should be noted that ABS aeration fans of DamaTajhiz Fan Coil Units can resist up to 100 °C. Moreover, these fan coil units have single-phase three-speed electromotors that are manufactured under the license of the Italian Sisme Company.

The motor has 8 bars of reliable operating pressure for the DamaTajhiz Fan Coil Unit and is suitable for buildings with up to 20 floors.

Frame Specifications

It consists of an inner and outer frame. The inner frame is made of high quality 1mm thick galvanized sheet which is connected to the outer frame with automatic screws and rivets.


The device is insulated with a glued back compressed Airo Flex insulator (3mm thick compressed polyethylene) to prevent heat loss and cold and reduce device noise.


Aluminum plate and washable filter can eliminate particles in the air, given filtering type. In these filters, grid sheets are put on each other.

Distillation Pan

Galvanized distillation pan with a proper slope to direct distilled water from coil surface in warm seasons

Advantages of DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000

  • Highly appropriate size to be installed on false ceilings with low height
  • Three standard speeds with low noise
  • Electronic heating coils can be used if customer demands
  • Easy access to fan and electromotor for periodic maintenance
  • Easily usable deaeration valve
  • It can be manufactured with two air return conditions: from below and from back
  • Washable and high durable filter with easy installation and replacement
  • Insulator used under distillation pan to prevent it from sweating
  • High heating capacity with three-row coil

Determination of DamaTajhiz Fan Coil Units Capacity

One of the most important things in selecting fan coil units is to determine their capacities. For this purpose, you can use the following approximated table:

Fan coil capacity determination table

Warranty and After-sale Services for DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000

DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000 has 18 months of warranty along with 20 years of after-sale services of DamaTajhiz Company.

Type built-in ceiling
Function heating & cooling
Height 540 میلیمتر
Length 1750 میلیمتر
Width 230 میلیمتر
Power Consumption تکفاز 220 ولت
Capacity 1000
نوع کالا Fan Coil

perfect brand

thakns for sharing


برند معتبر

دماتجهیز برند معتبریه و با توجه به سابقه و عملکرد چشم گیر سالیان شرکت دماتجهیز با اطمینان می شه خرید کرد

Write your review! !

Write a review

Path: > > > > DamaTajhiz Concealed Ceiling Fan Coil Unit DT.CFC1000
Model DT.CFC1000
Installation position


Aeration capacity (CFM) 1000
Coil Specifications Row number 3
Size of copper tubes (inch) 3/8"
Fin per inch (Fpi) 12
Cooling Total Cooling capacity (BTU/Hr) 30,500
Water Flow (GPM) 6.5
Heating Total Heating capacity (BTU/Hr) 75,000
Water Flow (GPM) 7.5
Engine Number 2
Power (W) 2*45
Flow (A) 2*2.25
Dimensions (cm) Length 168
Width 54
Height 23
