Turbo Cast-Iron Boiler by ChauffageKar with 13 Sections

Expert Guide to Buying Turbo Cast-Iron Boiler with 13 Sections

Turbo Cast-Iron Boiler ChauffageKar is made of fire-resistant cast iron, resistant to corrosion and thermal shock, featuring a high heat transfer coefficient. It is produced and offered in sectional form (8 to 15 sections) and ensures uniform water circulation across all boiler sections.
On the DamaTajhiz reference and online store, technical information and guaranteed prices for different types of boilers with original warranty are provided to ensure you have an optimal and smart purchasing experience.

Features of Turbo Cast-Iron Boiler ChauffageKar with 13 Sections

• The dimensions and price listed for this ChauffageKar cast-iron boiler include the outer casing.
• The Turbo Cast-Iron Boiler ChauffageKar with 13 sections is equipped with a heat shield that prevents the flame from touching the cast-iron sections of the hot water boiler.
• Typically, after calculating the required capacity, a 20% safety factor is added to the boiler’s calculated heating capacity.
• The Turbo Cast-Iron Boiler ChauffageKar with 13 sections has a maximum working pressure of 4 bar, making it suitable for buildings up to 13 floors (approximately 40 meters). The maximum operating temperature for these cast-iron boilers is 105 °C.
• This boiler is used in boiler rooms to provide space heating, hot water, and to supply heat to single-effect hot water chiller generators.
• ChauffageKar turbo cast-iron boilers allow installation of gas or diesel burners. Any price changes are communicated during the purchase inquiry.
• Turbo Cast-Iron Boilers from ChauffageKar Industrial Company comply with mandatory standards 4472 and 4473 and hold the ISO 9001:2008 quality management certificate from SGS Switzerland.
• The operation of the ChauffageKar cast-iron boiler is guaranteed for 10 years, unconditionally if installed correctly, with damaged sections replaced.
• To calculate the required boiler capacity based on the number of units, building area, usage type, presence of a swimming pool, etc., you can consult DamaTajhiz experts.
• Full insulation of the casing minimizes heat loss, and the ease of maintenance makes these boilers suitable for residential towers, factories, office buildings, hospitals, sports halls, and recreational centers.
• For a rough calculation of the required cast-iron boiler capacity, multiply the useful building area by 100 (kcal) and add 6000 kcal for each residential unit to cover hot water consumption. For example, for a building of 2500 m² with 18 units: 358,000 kcal/hr = (18×6000) + (100×2500).

Advantages of Sectional Cast-Iron Hot Water Boilers over Steel Ones

• Better price and warranty compared to standard steel boilers.
• Ability to replace damaged sections and easier maintenance compared to integrated steel boilers.
• Smaller dimensions and easier transport since the sections can be separated.

Turbo Cast-Iron Boiler Capacity Calculation and Installing Tips

• The key consideration when using cast-iron boilers is the working pressure limit and the need for sealing the joints between sections after installation.
• Installation of a thermometer and pressure gauge to display the boiler’s water temperature and the building heating system pressure is mandatory on every ChauffageKar cast-iron boiler.
• Installing a submerged thermostat with a temperature range of 30–90 °C (or 30–110 °C) to regulate the boiler temperature and control the burner relay is also required.
• If there are more than 6 units, using two central heating boilers in parallel, each covering 70% of the required capacity, ensures stable heating and hot water supply.
• Since all main boiler room equipment is installed on pre-prepared concrete foundations according to the layout plan, ensure the foundation is properly set before installing the main equipment, including the cast iron boiler by ChauffageKar.


Factors Affecting the Lifespan of ChauffageKar Cast-Iron Boilers

For boilers with a heating capacity above 300,000 kcal/hr, the following factors help increase their lifespan:

• Uniform and continuous wall thickness of the cast-iron boiler body.
• Properly adjusted burner flame (blue flame, longitudinal flow inside the boiler).
• Adequate combustion chamber length, preventing flame contact with rear or middle sections.
• Correct burner selection with heating capacity up to 20% above the boiler’s capacity.
• Use of a suitable resin water softener or descaler in the required quantity and size for the heating system pipes.
• Proper sealing between boiler sections during installation and avoiding excessive water pressure (too many floors) which is harmful to the boiler.
• Choosing an appropriately sized central heating boiler so that even in the coldest days, it does not operate continuously without breaks.

Warranty for Turbo Cast-Iron Boiler ChauffageKar with 13 Sections

On the DamaTajhiz reference and online store, technical information and prices of ChauffageKar cast-iron boilers with original warranty are provided for a smart and reliable purchase experience.
DamaTajhiz holds an official trade license from the Heating and Air Conditioning Union, has the e-trust mark, and has been operating its online store since 1383 (Solar Hijri) from its Tehran headquarters.
Turbo Cast-Iron Boiler ChauffageKar with 13 Sections, like other ChauffageKar products, comes with a 10-year warranty and full technical support and after-sales services nationwide.
