Cast Iron Boiler with 172000 Heating Capacity Model L90-7

Guide to Buying a Cast Iron Boiler with 172000 Heating Capacity

The Cast Iron Boiler by Iran Pipe & Machinery Co. (MI3) Model L90-7 is made from high-quality cast iron alloy, designed to distribute heat evenly for maximum efficiency. These boilers, with high efficiency and a thermal performance of over 90%, are suitable for residential units, office spaces, and industrial or sports facilities, and are installed on the floor. On DamaTajhiz's official store website, technical specifications and guaranteed prices for various cast iron boilers with original warranty are provided to ensure you enjoy an optimal and smart purchasing experience.

Features of L90-7 Cast Iron Boiler by Iran Pipe & Machinery Co. (MI3)

• The Cast Iron Boiler by Iran Pipe & Machinery Co. (MI3) Model L90 has laboratory certification regarding central heating, domestic hot water, and measurement of capacity and efficiency from the Institute of Standards & Industrial Research of Iran.
• The working pressure of the Cast Iron Boiler by Iran Pipe & Machinery Co. (MI3) Model L90 is 4 bar.
• L90 cast iron boilers by MIT are produced and offered in 8 different models with capacities ranging from 172,000 to 560,000 kcal/hr.
• The final price of the above MI3 cast iron boiler will be provided at the time of purchase inquiry.
• The provided dimensions and prices for the above hot water cast iron boilers include the casing.

Advantages of Cast Iron Boilers Compared to Integrated Steel Boilers

• Smaller dimensions and easier transportation due to detachable sections of the boiler.
• Ability to replace a damaged section and easier maintenance compared to steel boilers.
• More affordable price and warranty for cast iron boilers compared to standard steel boilers.

MI3 Cast Iron Boiler Capacity Calculation

• To estimate the required boiler power, first multiply the building’s useful floor area by 100 (kcal), then add 6,000 kcal per residential unit to account for domestic hot water. For example, for a building with 2,500 m² of useful area and 15 apartments, the required heating power is: 340,000 kcal = (15×6000) + (100×2500).
• To calculate the required cast iron boiler capacity based on number of units, floor area, building usage, presence or absence of a swimming pool, etc., you can consult DamaTajhiz experts.
• Usually, after the above calculation, up to 20% is added as a safety factor to the calculated boiler capacity.
• The most important consideration when using cast iron boilers is the working pressure limitation and the need to seal the joints between boiler sections after installation.
• If there are more than 6 apartment units, using 2 central heating boilers in parallel, each with 70% of the required capacity, ensures reliable heating and hot water supply.
• Installing a thermometer and manometer on each boiler to display water temperature and system pressure is mandatory.
• Also, installing an immersion thermostat with a temperature range of 30 to 90°C (or 30 to 110°C) for controlling boiler temperature and sending on-off commands to the burner relay on each boiler is required.

• Since all main boiler room equipment, including the central heating boiler, is installed on pre-built concrete foundations according to layout plans and exact locations, it is necessary to prepare the required concrete foundations according to defined dimensions and standards before installing main boiler room equipment, including the cast iron radiator boiler.

Minimum Required Equipment for a Simple Boiler Room

1. Central heating boiler (cast iron or steel)
2. Immersion thermostat
3. Thermometer and manometer (installed on the boiler)
4. Burner (fuel type?)
5. Burner gas hose and filter of correct size (or diesel nozzle and filter for diesel burner)
6. Hot water tank (coil or double-wall)
7. Temperature and pressure safety valve (installed on the hot water tank)
8. Circulation pump (usually 2-inch HV, 2-inch AA, 2-inch A6, 2-inch A7, etc., based on floor area)
9. Wall-mounted thermostat (controls circulation pump)
10. Hot water return pump (frequently 1-inch line pump)
11. 1-inch flange for hot water return pump
12. Expansion tank (galvanized or aluminum)
13. Expansion tank float (metal or plastic ball)
14. Boiler room electrical panel (minimum 5 kW)

Warranty for the Cast Iron Boiler by Iran Pipe & Machinery Co.

The warranty period for the Cast Iron Boiler by Iran Pipe & Machinery Co. (MI3) Model L90 is 5 years from the delivery date. Additionally, these boilers have lifetime after-sales service.
